Nozzles from Flashpoint Fuels Ltd.

Fill-Rite 1 in Ultra Hi-Flow Nozzle

Model: N100DAU13G

Fill a 200 gallon tank in less than 7 minutes. That's real time saved every time you fill the tank. Industry leading flow isn't the only reward you will reap. The patent pending UL listed Ultra Hi-Flow nozzle takes fuel transfer to a new level. For transfer of gasoline, diesel, or kerosene to large fuel capacity farm, fleet, or construction equipment, there is simply no better choice.

Fueling has never been easier or quicker. Don't let your nozzle slow up your work when it is most critical. At Fill-Rite, we understand that time is money.

Features & Benefits

• UL listed for gasoline, diesel and kerosene
• 1 in NPT-F inlet, 1 1/8 in OD spout
• Three-position latch for automatic flow at 30, 24 and 8 GPM
• Angled outlet to minimize hose wear
• 50 PSI working pressure
• Heavy duty hanging hook compatible with all Fill-Rite products
• Automatic shut-off
• Convenient one-finger hold-open clip to set flow rate
• Rated to -20 Fahrenheit operation
• Insulated hand grip to minimize hot and cold handling
• Minimal spray pattern to reduce foaming and false shut offs
• Large spout spring to hold nozzle in place
• Viton seals and o-rings for smooth valve operation
• Patent pending
• Made in USA

Fill-Rite 1 in. UL Manual Nozzle with Hook

Model: FRHMN100S

These nozzles are well suited for a broad range of high flow fueling applications from farm tractors and combines, heavy earth-moving equipment, fleet re-fueling, to above ground storage tanks and portable truck mounted fueling operations. This rugged series of manual nozzles will provide years of service with minimal down time and quick fueling.

Features & Benefits

• Compatible with gasoline and diesel
• UL/cUL listed
• 1 in aluminum nozzle
• 1 in NPT-F outlet
• Manual nozzle
• 50 PSI working pressure
• Integral hanging hook compatible with all Fill-Rite products
• Minimal spray pattern to reduce foaming and false shut-offs
• Viton seals and o-rings for smooth valve operation
• Rated to -20°F operation
• Made in USA

Fill-Rite 1 in Automatic Nozzle with Hook

Model: N100DAU12

Fill a 200 gallon tank in less than 7 minutes. That's real time saved...every time you fill the tank. Industry leading flow isn't the only reward you will reap. For transfer of gasoline, diesel, or kerosene to large fuel capacity farm, fleet, or construction equipment, there is simply no better choice.

Features and Benefits

• Suitable for gasoline, diesel, E15, biodiesel up to B20, and kerosene
• Integral hook and spout spring
• Three locking flow-rate positions
• Heavy duty aluminum body
• No pressure/no flow feature for added safety
• Red nozzle cover
